    An all unique circuit design called "Master Sound Discrete DAC", together with a further refined sound quality Network Module as core technology result in the ultimate Network Audio Player/DAC, the N-01XD. The outcome of ESOTERIC's passion that strives for the original master sound.

    Spec description

    Digital audio input



    ES-LINK

    1 (L/R)

    Input signal formats



    Linear PCM

    44.1k to 768kHz, 48bit (ES-LINK5 format)

    DSD

    2.8MHz, 5.6MHz, 11.2MHz, 22.4

    XLR

    1

    Input level

    5.0Vp-p

    Input impedance

    110Ω

    Input signal formats



    Linear PCM

    32k to 192kHz, 16bit / 24bit (AES/EBU format)

    DSD

    2.8MHz (ES-LINK1, ES-LINK2, DoP format)

    RCA

    1

    Input level

    0.5Vp-p

    Input impedance

    75Ω

    Input signal formats



    Linear PCM

    32k to 192kHz, 16bit / 24bit (IEC60958 format)

    DSD

    2.8MHz (DoP format)

    OPTICAL

    1

    Input level

    –24.0 to –14.5dBm peak

    Input signal formats



    Linear PCM

    32k to 192kHz, 16bit / 24bit (IEC60958 format)

    DSD

    2.8MHz (DoP format)

    USB

    1 (B type)

    Input signal formats



    Linear PCM

    44.1k to 384kHz, 16bit / 24bit / 32bit

    DSD

    2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz

    ETHERNET

    1 (1000BASE-T)

    Input signal formats



    Linear PCM

    44.1k to 384kHz, 16bit / 24bit / 32bit (stereo)
    • 32bit audio files only support integer formats.

    DSD

    2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz (stereo)

    Supported file formats



    PCM lossless

    FLAC, Apple Lossless (ALAC) , WAV, AIFF, MQA

    DSD lossless

    DSF, DSDIFF (DFF) , DoP

    Compressed audio

    MP3, AAC (m4a container)

    USB DRIVE

    2 (Front, Rear)

    Supported file formats

    FAT32, NTFS, Single partition; USB 2.0 or faster recommended

    maximum Power Supply

    0.5A

    Input signal formats



    Linear PCM

    44.1kv to 384kHz, 16bit / 24bit / 32bit (stereo)
    • 32bit audio files only support integer formats.

    DSD

    2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz (stereo)

    Supported file formats



    PCM lossless

    FLAC, Apple Lossless (ALAC) , WAV, AIFF, MQA

    DSD lossless

    DSF, DSDIFF (DFF) , DoP

    Compressed audio

    MP3, AAC (m4a container)

    Analog audio outputs



    XLR/ESL-A

    1 pair (L/R)

    Output level

    5.0Vrms (1kHz, 10kΩ loaded)

    Output impedance

    40Ω

    RCA

    1 pair (L/R)

    Output level

    2.5Vrms (1kHz, 10kΩ loaded)

    Output impedance

    15Ω

    Clock sync input



    BNC

    1

    Input frequency

    10MHz (±10ppm)

    Input impedance

    50Ω

    Input level



    Rectangle wave

    equivalent to TTL level

    Sine wave

    0.5 to 1.0Vrms

    Clock sync output



    BNC

    1

    Output level

    TTL level equivalent (75Ω load)

    Output frequency

    44.1k / 48kHz

    Output frequency accuracy

    ±0.5ppm

    General



    Power supply





    AC 230V, 50Hz



    AC 120V, 60Hz



    AC 220V, 60Hz

    Power consumption

    38W

    External dimensions (W×H×D)

    445 × 162 × 438mm
    17-⅝" × 6-½" × 17-¼" (including protrusions)

    Weight

    26.3kg / 58 lb

    Included accessories

    Power cord × 1
    HDMI cable × 1
    Felt pads × 4
    Owner's manual × 1
    Warranty card × 1



    Audio performance

    Frequency response

    5Hz to 70kHz (–3dB)

    S/N ratio

    113dB

    Distortion

    0.0007% (1kHz)
