MAGNAT MONITOR S80 ATM - PAIR
Dolby Atmos 3-way bass reflex floorstanding speaker
The 702 Signature is finished in exclusive Datuk Gloss and features optimised crossovers, three Aerofoil Profile bass drivers, a Continuum cone midrange and a Carbon Dome tweeter housed in a Solid Body Tweeter-on-Top enclosure.
Crafted. Honed. Perfected.
702 Signature is the ultimate expression of the 700 Series range. Based on the versatile 702 S2, it transforms sound using technologies from the 800 Series Diamond range as well as featuring bespoke Signature optimisations.
Optimised tweeter housing
Milled from a solid block of aluminium, the
Solid Body Tweeter housing design creates an acoustically optimised housing that is exceptionally inert and resistant to resonances.
Carbon Dome tweeters are purpose-built for the 700 Series and deliver pinpoint imaging accuracy and detailed insight in to your music.
Truly amazing sound
Voices and instruments are delivered with purity and precision, thanks to the smooth, accurate Continuum cone midrange driver.
Clean and revealing
The midrange drivers in 702 Signature feature
a decoupled design, developed from the 800 Series Diamond. Decoupling reduces cabinet coloration and boosts midrange clarity.
Refined, articulate bass
The Aerofoil Profile bass cone has a unique wing-shaped form, providing stiffness and rigidity where it's needed most. The result: accurate, dynamic bass.
3-way vented-box system
Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Aerofoil™ Profile bass cones
1x ø25mm (1 in) Carbon Dome
1x ø150mm (6 in) Continuum cone
3x ø165mm (6.5 in) Aerofoil Profile bass
6dB at 28Hz and 33kHz
46Hz - 28kHz ±3dB
90dB spl (2.83Vrms, 1m)
2nd and 3rd harmonics (90dB, 1m)
<1% 86Hz - 28kHz
<0.5% 110Hz - 20kHz
8Ω (minimum 3.1Ω)
Reccomended amplifier power
30W - 300W into 8Ω on
Height: 994mm (39 in) cabinet only 1087mm (42.8 in) including tweeter
Width: 200mm (7.9 in) cabinet only 366mm (14.4 in) including plinth
Depth: 337mm (13.3 in) cabinet only 364mm (14.3 in) inc. grille and terminals 452mm including plinth
29.5kg (65 lb)
B&W 702 signature
Diffusori veramente ben suonanti atti a definizione di bassi , medi e acuti strepitosi
