MCINTOSH MT 10

Precision Turntable

• Belt drive
• Moving Coil cartridge
• Illuminated speed meter

With tracking force, anti-skate and cartridge position preset at the factory, the McIntosh MT10 Precision Turntable delivers high performance LP playback with minimal set up. A custom tonearm features a rigid, dural-aluminum arm-tube gimbaled in two sapphire (horizontal) and two ceramic (vertical) bearings for the least possible friction. A .5mV moving coil cartridge is included, and features an ebony body with an elliptical stylus. Enjoy a new level of music with the MT10 turntable.

Cartridge Specifications

• Cartridge Type

Moving Coil, Low Output

• Output Level

0.5 mV at 5 cm/s

• Load Impedance

400 to 500 Ohms recommended

• Frequency Response

20Hz to 50kHz

• Channel Separation

Greater than 30dB at 1Khz

• Compliance

6 x 10^-6 cm/dyne

• Recommended Tracking Force

2.4 g

• Channel Difference

Less than 0.3dB at 1kHz

• Total Mass

11 g

• Stylus

Elliptical Diamond

• Cantilever Material

Aluminum

Tonearm Specifications

• Bearing

Sapphire and Ceramic

• Arm Tube

Dural-Aluminum

• Counterweight

Eccentric

• Adjustments

Vertical Tracking Angle, Antiskate, Azimuth

Turntable Specifications

• Playback Speeds

33-1/3, 45 and 78 rpm

• Motor Type

DC Brushless

• Speed Control

Electronic w/ braking feature

• Platter

Silicon Acrylic

• Platter Bearing

Magnetic Suspended Ceramic

• Signal To Noise Ratio

41dB - 44dB

• Wow & Flutter

0.10% - 0.15%

Connectivity

• Stereo Outputs Unbalanced

1

Control

• Power Control Input

1

• Power Control Output

1

• Platter Light

Yes

• Speed Control Fine Adjustment

Yes

General Specifications

• Dust Cover Included

No

Weights & Dimensions

• Dimensions (W x H x D)

17-1/2" (44.45cm) x 8-13/16" (22.38cm) x 21" (53.34cm)
Note: Tone Arm Height will vary depending on the type of Cartridge installed.

• Weight

42 lbs (19 kg)

• Shipping Weight

63 lbs (28.6 kg)
