LEHMANN AUDIO BLACK CUBE STATEMENT

Phono stage MM / MC. Infinite possibilities of adaptation of head impedance.
Gain and load selectors with gold contacts.
RIAA Stadium made with high precision MKS paper capacitors.
Low noise metal film resistors. Input and output with golden RCA. External transformer.

SPECS

Sensitivity for output level 775 mV/0 dB (with activated high gain jumper) MM: 7.4 mV/1 kHz; MC: 0.74 mV/1 kHz
Gain 1 kHz MM: 41 dB; MC: 61 dB
Maximum input level MM: 58 mV; MC: 5.6 mV
Signal to noise ratio (RMS unweighted) MM: 78 dB; MC: 57 dB
Gain 31 dB, 41 dB, 51 dB, 61 dB
Channel separation > 85 dB at 10 kHz
Input impedance 47 kohms, 1 kohm, 100 ohms 1 x custom load
Output impedance < 100 ohms
Input capacitance 100 pF
Channel mismatch typ. 0.5 dB
Bass filter 50 Hz, 6 dB/oct.
Power consumption app. 1 VA
Outer dimensions W x D x H 103 mm x 108 mm x 45 mm
Weight 0.28 kg netto
