MARANTZ MCR 60N DAB

Marantz MCR 60n DAB – All-in-One Stereo Hi-Fi System with CD, HEOS, HDMI eARC and MM Phono

The Marantz MCR 60n DAB is a compact and comprehensive all-in-one Hi-Fi system designed to bring together the main music and home entertainment sources in a single component. It combines stereo amplification, CD player, DAB/DAB+/FM tuner, MM phono input, HEOS network streaming, Bluetooth, HDMI eARC and high-resolution audio support.

With an output of 65 W + 65 W into 4 Ohms, the MCR 60n DAB can drive compact and floorstanding stereo speakers, providing a particularly versatile solution for anyone looking for a complete system without sacrificing the functionality associated with modern Hi-Fi.

Key Features

• 2-channel all-in-one stereo Hi-Fi system
• 65 W + 65 W output into 4 Ohms
• Speaker A/B operation
• Bi-amping function
• Parallel BTL mode
• Integrated CD player
• CD, CD-R/RW, WMA and MP3 compatibility
• HEOS network streaming
• Spotify Connect, TIDAL, Deezer, Amazon Music, Qobuz and Pandora
• Apple AirPlay 2
• Roon Ready
• Internet Radio
• DAB, DAB+ and FM tuner
• Integrated Bluetooth
• Bluetooth transmission to compatible headphones
• Integrated MM phono input
• HDMI eARC/ARC for TV connection
• Optical digital input
• Rear USB-A port for audio file playback
• PCM support up to 384 kHz / 32-bit
• DSD support up to 11.2 MHz
• Gapless playback for FLAC, WAV and DSD
• Ethernet and Wi-Fi connectivity
• Dirac Live upgrade-ready
• Dedicated subwoofer output
• Assignable AUX Pre Out
• Headphone output
• Bass, treble and balance controls
• 3-line low-noise OLED display
• Programmable timer and Sleep Timer
• Available in Black and Champagne Gold

An Entire Hi-Fi System in a Single Component

The MCR 60n DAB is designed to provide a complete listening experience without requiring multiple separate components. A stereo amplifier, CD player, digital and analogue radio tuner, HEOS streaming platform, DAC and numerous inputs and outputs are integrated into a single chassis.

This configuration makes it possible to connect a pair of speakers and create a complete stereo system while maintaining compact dimensions and an elegant appearance. It is particularly suitable for living rooms, studies, secondary rooms and Hi-Fi systems where simplicity and versatility are important.

65 W per Channel Stereo Amplification

The amplification section delivers 65 W per channel into 4 Ohms, with a configuration designed to drive different types of loudspeakers. Advanced modes such as bi-amping and Parallel BTL are also available, allowing the system to be configured according to the requirements of the installation.

Speaker A/B management also allows two pairs of speakers to be used, further increasing the flexibility of the system.

HEOS: Music Streaming and Multiroom

Thanks to the HEOS platform, the MCR 60n DAB provides access to music streaming services through the home network. Supported services include Spotify Connect, TIDAL, Deezer, Amazon Music, Qobuz and Pandora, as well as Internet Radio.

AirPlay 2 compatibility allows content to be streamed from Apple devices, while Roon Ready certification enables integration into systems based on the Roon ecosystem.

The HEOS platform also allows the MCR 60n DAB to be integrated into a multiroom system, coordinating music playback between multiple compatible rooms.

Hi-Res Playback up to 384 kHz / 32-bit

The MCR 60n DAB supports high-resolution audio file playback through its rear USB-A port. Compatibility extends up to PCM 384 kHz / 32-bit and DSD 11.2 MHz, providing extensive support for modern digital music libraries.

Supported formats include DSD, WAV, FLAC, AIFF, ALAC, MP3, WMA and AAC. Gapless playback for FLAC, WAV and DSD allows recordings designed as a continuous musical sequence to be enjoyed without unwanted interruptions.

Integrated CD Player

For users with a physical music collection, the MCR 60n DAB incorporates a CD player compatible with CD, CD-R/RW, WMA and MP3. This makes it possible to continue enjoying a disc collection without adding a separate player.

The combination of CD playback, streaming, USB and Bluetooth makes the system suitable for both traditional music collections and modern digital sources.

Integrated MM Phono Stage

Vinyl enthusiasts can connect a turntable fitted with an MM (Moving Magnet) cartridge directly to the system. The integrated phono stage features a sensitivity of 2.5 mV and an impedance of 47 kOhms, with a frequency response from 20 Hz to 20 kHz.

The MCR 60n DAB can therefore bring vinyl, CDs, streaming music and high-resolution digital files together within the same Hi-Fi system.

HDMI eARC for TV and Home Entertainment

The presence of an HDMI eARC/ARC input allows the television to be connected directly to the Marantz system for movies, TV programmes, streaming content and gaming.

This solution brings high-quality stereo reproduction to home entertainment while keeping the configuration simple and tidy. Control can also be integrated with a compatible television remote.

Dirac Live and System Management

The MCR 60n DAB is ready for an upgrade with Dirac Live, room correction technology that allows the acoustic behaviour of the system to be adjusted according to the listening environment.

The system also provides separate bass, treble and balance controls, allowing the sound to be customized according to the connected speakers and the characteristics of the room.

Compact Marantz Design

The MCR 60n DAB combines compact dimensions with Marantz's distinctive design language. The front panel incorporates a 3-line low-noise OLED display, intuitive controls and a switchable illuminated status LED.

The Black and Champagne Gold finishes allow the system to complement different interior configurations. Measuring just 280 × 303 × 111 mm, it can be installed easily in spaces where a conventional Hi-Fi system would be too large.

Technical Specifications
