MARTIN LOGAN NEOLITH - PAIR

Three-way floorstanding electrostatic/hybrid speaker with phenolic resin polymer enclosure. Dual 381mm aluminum cone woofers in the rear bass reflex port and a 305mm aluminum cone in the front air suspension port. 1220x560mm CLS XStat™ curved electrostatic ribbon midrange/tweeter with controlled dispersion. The electrostatic panel is joined to the bass module using ultra-rigid AirFrame Blade Design technology. Power 50-1300W. Efficiency 90dB. Impedance 4ohm. Vojtko™ crossover with premium components, 1% resistors, and polypropylene capacitors. Bass control 0, -4, and -8dB. WBT bi-wiring connectors. ETC™ decoupling tips included.

Other Features

Frequency Response: 23-22,000 Hz ± 3 dB

Recommended Amplifier Power: 20-1300 watts per channel

Horizontal Dispersion: 30°

Vertical Dispersion: 48-inch line source

Sensitivity: 90 dB/2.83 volts/meter

Impedance: Nominal: 4 ohms, 0.43 ohms at 20 kHz. Compatible with 4, 6, or 8-ohm amplifiers

Crossover Frequency: 60, 250-400 Hz

High-Frequency Transducer: XStat™ CLS™ electrostatic transducer. Panel Dimensions: 48 x 22 inches. Radiating Area: 6,832 cm²

Low-Frequency Transducer: Rear: 15-inch canister, high-excursion, rigid aluminum cone with extended-throw drive assembly. Extensively vented triple-loop short-circuit motor and 4-layer voice coil eliminate compression and distortion. Front: 12-inch die-cast aluminum alloy chassis, high excursion, rigid carbon fiber sandwich cone with long-throw design, 3-inch diameter copper-clad aluminum flat wire voice coil with vented pole piece and under-vented spider to reduce power compression.

Cabinet: Phenolic resin polymer: dense substrate with excellent mechanical strength to minimize cabinet vibration caused by woofer cone counterforces, providing an ideal baffle for the electrostatic panel and woofers.

Components: High-Pass Crossover: Heatsink-mounted 1% resistors, polypropylene capacitors, air-core inductors, dual toroidal audio transformers to drive the electrostatic element. Cross-Pass Crossover: Heatsink-mounted 1% resistors, toroidal inductors, supports user options to modify the sound output via jumper.

Audio Controls: Bass Control: 0dB, -4dB, -8dB Distance Control: 3 meters (or less), 4 meters, 5 meters (or greater)

Inputs: WBT-0705Ag Nextgen™ 5-way bi-terminal blocks equipped with high-conductivity fine silver filigree signal conductors. Fully insulated to CE and IEC compliance, providing protection from electrical shock. Free from eddy current effects. Maximum constant current 30 A, peak current 200 A. Palladium-plated metal outer shell.

Power consumption: Standby: 1 W each, Max: 15 W each.

Lighting: LED intensity control: On, Dim, Off.

Weight: 175 kg.

Dimensions: 189.9 x 76.9 x 87 cm.
