CANTON SMART AMP 5.1

Technical Specifications

New Canton Smart Connect 5.1 GEN2, Wireless AV Preamplifier with Dolby Atmos®

Wireless AV Preamplifier

Connections:

1 x HDMI® output (with ARC)

3 x HDMI® input (with 3D, 4K)

1 x digital (optical)

1 x digital (coaxial)

2 x analog (chinch)

5 x Pre-Out (chinch)

1 x Subwoofer output

Features

Bluetooth® 4.0

Dolby Digital decoder

DTS Digital Surround decoder

Stereo and surround sound

Bass, midrange, and treble controls

Touch panel on top

LED display

Special Features

Easy one-cable setup - just one cable to the TV and one cable to the power

IR learning function - controllable with the TV remote

Automatic on/off switch with the TV

Mode ECO - Selectable power saving mode (On/Off)

Bluetooth Select - Automatic Bluetooth input selection

IR Delete function - Easily delete unwanted learned functions

Direct input selection - Ideal for learnable smart remote controls

Lip-Sync - For precise speech synchronization

Equalizer - 3 presets to adjust the acoustics to the installation location

Easy Pairing - Easier connection to the source device

Dimensions (W x H x D x D) 24.5 x 5.2 x 14 cm

Weight 1.23 kg

Using the menu, the user can configure the Smart Connect 5.1 from a minimum of 2.0 channels up to a 7.1-channel system. The Smart Connect 5.1 provides 6 analog preamp outputs, which can be connected to active speakers and/or a subwoofer or powered power amplifiers via an RCA signal cable. Additionally, the Smart Connect provides 8 channels of wireless audio to drive other Canton Smart series wireless speakers.
