REGA NEO PSU MK2

Rega Neo PSU MK2 – External Power Supply for Rega Turntables

The Rega Neo PSU MK2 is a high-performance external power supply designed to significantly improve the performance of compatible Rega turntables. Engineered using advanced DSP technology and a high-stability crystal oscillator, the Neo PSU MK2 delivers extremely precise motor control, ensuring superior speed stability and reduced motor noise for a more accurate and musical vinyl playback experience.

By generating a near-perfect sinusoidal signal for the 24V motor, the Neo PSU MK2 enhances rotational accuracy and dramatically minimizes vibration. The result is improved timing, deeper detail retrieval and cleaner overall sound reproduction.

Thanks to the integrated electronic speed change and user-adjustable fine speed control, switching between 33⅓ and 45 RPM becomes effortless without the need to manually move the drive belt. The speed can also be fine-tuned with extreme precision using the rear adjustment system and supplied trim tool.

Styled to match the latest Rega electronics, the Neo PSU MK2 is the perfect upgrade for audiophiles looking to extract the maximum performance from their Rega turntable.

Key Features

• High-performance external power supply for Rega turntables
• DSP signal generator based on the technology used in the Planar 10 PSU
• High-stability crystal oscillator for extremely accurate speed control
• Electronic speed change between 33⅓ and 45 RPM
• User adjustable fine speed tuning with 0.01 RPM precision
• Advanced anti-vibration motor drive circuit
• Near-perfect sinusoidal waveform for smoother motor operation
• Redesigned enclosure matching the latest Rega components
• Improves rotational accuracy, reduces noise and enhances sound quality

Performance Upgrade for Rega Turntables

The Neo PSU MK2 dramatically improves the stability and accuracy of the turntable motor by replacing the standard power supply with a precision-controlled signal generator. The advanced motor drive circuit reduces unwanted vibration and electrical noise, resulting in smoother platter rotation and improved sonic clarity.

The integrated digital signal processing system divides the signal from the internal crystal oscillator into the exact frequency required to drive the motor at the selected speed. This ensures extremely accurate rotation and more natural, dynamic vinyl playback.

Compatible Rega Turntables

• Rega Planar 3 (2016 – current)
• Rega RP3
• Rega P3-24
• Rega RP6
• Rega P5
• Rega P7
• Rega RP40 Special Edition
• Rega RP8
• Older Rega turntables upgraded with the 24V motor kit

Technical Specifications

• Product type: External power supply for turntables
• Motor output: 24V AC bi-phase
• Motor protection: Resettable fuse
• Speed selection: 33⅓ RPM / 45 RPM electronic switching
• Speed fine adjustment: 0.01 RPM increments
• Signal generation: DSP generator with high-stability crystal
• Motor drive waveform: Low-distortion sinusoidal signal
• Power consumption: 7.2 W
• Input power supply: Rega PS1 adapter (24V AC)
• Dimensions (W × D × H): 180 × 155 × 50 mm
• Weight: approx. 0.6 kg

Why Upgrade to the Neo PSU MK2?

• Greater speed accuracy and pitch stability
• Lower motor vibration and background noise
• Convenient electronic speed switching
• Enhanced musical timing and soundstage
• Perfect upgrade for Rega audiophile turntables
