MUSICAL FIDELITY NU-VISTA CD PLAYER

Lettore CD e DAC. Bassissima distorsione e jitter. Linearità sorprendente. Dac 32bit/192KHz Delta Sigma (bit stream) doppio differenziale con sovracampionamento ottuplo. La scheda DAC è completamente sostituibile con una nuova scheda migliore se ci sarà in futuro. Impiego di valvole NUVISTOR. Circuitazione SMD. Ingressi digitali: 2 x ottico e 2 x coassiale. Uscite digitali: ottica e coassiale. Uscita analogica RCA e XLR. Trigger 12V.

Specifications

Output

Output impedance 50 ohms balanced or single ended

Output, digital 0dB level XLR output - 4.4V R.M.S. balanced nominal

RCA output - 2.2V R.M.S. single ended nominal

DAC - Balanced and single-ended outputs

DAC circuit 32 bit Delta-Sigma (bit stream) dual differential 8x over-sampling

Total correlated jitter <135 picoseconds peak to peak

Linearity <0.1dB down to -96dB

Performance

Frequency response 10Hz to 20 kHz -0.2dB max.

Channel separation >105dB 20 Hz to 20 kHz

Signal-to-noise ratio >117dB “a”- wtd.

Total harmonic distortion <0.003% 10Hz to 20 kHz

Connections

Line level outputs

1 pair line level RCA connectors, left and right outputs

1 pair line level XLR connectors, left and right outputs

Digital outputs

1 RCA coaxial S/PDIF up to 24 bit 192 kHz

1 optical S/PDIF up to 24 bit 96 kHz

Digital inputs

2x RCA coaxial S/PDIF up to 24 bit 192 kHz

2x optical S/PDIF up to 24 bit 96 kHz

Power requirement

Mains voltages 90-250VAC 50-60Hz universal

Power Consumption 20 Watts maximum (blue PWR LED lit)

Less than 0.5W in standby (orange STBY LED lit)

Weight

Unit only, unboxed 18.62 kg (41 lbs)

in shipping carton 26.12 kg (571/2 lbs)

Dimensions

Wide 483 mm (19”)

Height on standard flat feet 190 mm (7⅓”)

Height on pointed feet 212 mm (8⅓”)

Depth (front to back) including terminals 395 mm (153/4”)

Included accessories

IEC type mains lead 10-Amp type

Remote control Nu-Vista Integrated remote

Batteries LR03 or AAA, manganese alkaline type 2 off
